CAD XR is a visualization tool that allows users to view their CAD models in virtual reality. CAD XR Core provides our standard visualization software and conversion system, capable of optimizing and displaying CAD models of complexity ranging between 5-10 million triangles.

All Reviews:

4 user reviews - Need more user reviews to generate a score

Release Date:

May 24, 2017

Developer:

Lucid Sight, Inc.

Publisher:

Lucid Sight, Inc.

Tags

Popular user-defined tags for this product:

+

Sign in to add this item to your wishlist, follow it, or mark it as ignored

Features

Languages:

	Interface	Full Audio	Subtitles
English	✔

Title: CAD XR
Genre: Animation & Modeling, Design & Illustration, Utilities

Developer: Lucid Sight, Inc.

Publisher: Lucid Sight, Inc.

Release Date: May 24, 2017

Visit the website

View the manual

View update history Read related news View discussions Find Community Groups

Share Embed

Notice: At the request of the publisher, CAD XR is unlisted on the Steam store and will not appear in search.

About This Software

CAD XR is a visualization tool that allows users to view their CAD (computer-aided design) models in virtual or augmented reality. Our user interface is extremely simple and intuitive, though also allows for a wide array of customization options. Viewing models in CAD XR gives users a true visualization of their projects before any physical models are built.

In the construction or architecture industry? Walk through a building or view a structure in 1:1 scale to get a true sense of the size.

Work with microelectronics often? Increase the scale of a microchip to a size large enough to see every individual part.

In a medical field? Allow patients to judge the size of a prosthetic limb in VR to see what best fits them.

Save time and money by using virtual reality to examine CAD models before they're physically made.

CAD XR supports the following formats:

AutoCAD DXF (.dxf)
Collada (.dae)
Stereolithography (.stl)
Wavefront Object (.obj)

Technical Specs:

Windows-based application allows for high performance
VR compatible - Utilizes HTC Vive and Oculus Rift
Controller support for HTC Vive and Oculus Touch controllers for the VR viewer
Easy hand and grip controls to allow fluid model manipulation in the VR viewer
Built-in 3D desktop viewer lets users view and play around with a model
Shows the triangle count of loaded models in the 3D viewer
Supports up to 10 million triangles
Displays a coordinate system and viewcube with respect to the 3D model
Simple and intuitive mouse controls for 3D desktop viewer
Gives users the freedom to export converted files to any specified destination
Files can be sorted per the user’s needs (by date, name, or size)
User-friendly tool tips are always available to provide assistance
Supports backwards-compatible x64 architecture

System Requirements

Minimum:

OS *: Windows 8, Windows 10
Processor: Intel i5-4590 equivalent or greater
Memory: 8 GB RAM
Graphics: NVIDIA GTX 970 / AMD 290
Storage: 800 MB available space

* Starting January 1st, 2024, the Steam Client will only support Windows 10 and later versions.
