CAD XR is a visualization tool that allows users to view their CAD (computer-aided design) models in virtual or augmented reality. Our user interface is extremely simple and intuitive, though also allows for a wide array of customization options. Viewing models in CAD XR gives users a true visualization of their projects before any physical models are built.
​
In the construction or architecture industry? Walk through a building or view a structure in 1:1 scale to get a true sense of the size.
​
Work with microelectronics often? Increase the scale of a microchip to a size large enough to see every individual part.

In a medical field? Allow patients to judge the size of a prosthetic limb in VR to see what best fits them.
​
Save time and money by using virtual reality to examine CAD models before they're physically made.

CAD XR supports the following formats:

• AutoCAD DXF (.dxf)

• Collada (.dae)

• Stereolithography (.stl)

• Wavefront Object (.obj)

Technical Specs:

• Windows-based application allows for high performance

• VR compatible - Utilizes HTC Vive and Oculus Rift

• Controller support for HTC Vive and Oculus Touch controllers for the VR viewer

• Easy hand and grip controls to allow fluid model manipulation in the VR viewer

• Built-in 3D desktop viewer lets users view and play around with a model

• Shows the triangle count of loaded models in the 3D viewer

• Supports up to 10 million triangles

• Displays a coordinate system and viewcube with respect to the 3D model

• Simple and intuitive mouse controls for 3D desktop viewer

• Gives users the freedom to export converted files to any specified destination

• Files can be sorted per the user’s needs (by date, name, or size)

• User-friendly tool tips are always available to provide assistance

• Supports backwards-compatible x64 architecture
