Virtual Circuit Board is the sandbox drawing-based logic simulator where you can build, program, decorate, and simulate anything from simple monochrome circuits to complex and colorful computers. Play with digital logic in this sandbox-only experience.
All Reviews:
Very Positive (244) - 93% of the 244 user reviews for this game are positive.
Release Date:
Oct 6, 2023
Developer:
Publisher:

Sign in to add this item to your wishlist, follow it, or mark it as ignored

Buy Virtual Circuit Board



About This Game



Virtual Circuit Board, or VCB, is a sandbox-only drawing-based logic simulator featuring an assembler and a powerful simulation engine. All of it designed to give you the freedom to build and experiment with logic circuits to your heart’s content.

Set your own goals

In VCB you will set your own goals of what and how you want to build, it does not come with tutorials, levels, or challenges, and it will not teach you digital logic or assembly. VCB's development philosophy is aimed toward delivering a fresh sandbox experience for players who already have some basic knowledge about logic gates and circuits.

Powerful Simulation

High-performance tick-based simulation, where signals propagate between components one tick at a time. Simulate with a frequency of up to millions of updates per second.

Assembly

Assembly editor in which you can define your own instructions, allowing you to create a program that will be assembled into a Virtual Memory accessible by your circuits.

Editing and Simulating

Working in VCB is separated in two modes, while editing you can use the drawing tools to modify your circuit and the assembly editor to write programs, and during simulation you can see your circuit running, interact with it, and watch the assembly instructions being executed.

Drawing-based Interface

Build circuits by drawing color-coded entities like logic gates and traces, and use the specialized tools such as the Array to optimize your workflow by drawing multiple traces simultaneously. Both the electronic components and the traces support multiple input and output connections.

Decoration

Customize the appearance of circuits by drawing in the decoration layers that override the component's default colors. This allows you to create things such as buttons and labels that change appearance depending on the component's state.

System Requirements

Windows
SteamOS + Linux
    Minimum:
    • Requires a 64-bit processor and operating system
    • OS: Windows 10
    • Processor: 3.0 GHz+
    • Memory: 8 GB RAM
    • Graphics: OpenGL 3.3+ / 2 GB VRAM / 1366 x 768
    • Storage: 300 MB available space
    Recommended:
    • Requires a 64-bit processor and operating system
    Minimum:
    • OS: Ubuntu 18.04+
    • Processor: 3.0 GHz+
    • Memory: 8 GB RAM
    • Graphics: OpenGL 3.3+ / 2 GB VRAM / 1366 x 768
    • Storage: 300 MB available space
    Recommended:
